Brief Introduction
Beta 2.5 |
The Sony VPL EX246 model is an LCD projector with XGA 1024 x 768 resolution and a contrast of 3000:1. The projector can illuminate a picture width of up to 493 cm thanks to its 3200 Ansi lumens. In room light, however, the picture width should ideally be less than 329 cm. The model is also Full HD 1080P compatible. The projector was launched in 2013 and is no longer sold by the manufacturer.
|
| Display Type |
3 x 0,63" LCD TFT Panel
XGA 4/3 Liquid Crystal Display
|
| Ansi-Lumen |
Projector |
3200 / 1700 im Eco Mode |
Screen |
1067 Lux (200 cm Screen width) |
| Contrast |
3000:1 full on/off |
3000:1 full on/off
|
| Black Level |
1,0667 min. Lumen |
0,356 min. Lumen |
| Offset |
-
|
| Resolution |
XGA 1024 x 768
786.432 Pixel
UXGA 1600 x 1200 compressed |
| Video Modes |
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with a little more ambient light, max. 200 lumens. |
| Light Source |
210W Lamp
Article Nr.: LMP-E212
|
|
| Light Life |
3000 h. 7000 h. in eco Mode |
| Operating Costs |
|
|
280 - 454 cm
|
 |
|
Lux: |
1067 Lux |
|
Room light max.: |
213 Lux |
|
Candela pro m²: |
339 cd/m² |
|
Foot-Lamberts: |
99 fL |
|
 |
|
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,62 |
| Objective |
- |
| Throw Ratio |
1,40-2,27:1 show |
| Audio |
2 x 8W |
| Connections |
HDMI in
2 x D-sub 15 pin in 1 x out
S-Video in
Cinch Video in
Mini Jack Audio in
RS232C
RJ45 in
USB Typ A,B
Mikrofon in |
| Ceiling Mounting |
Yes, is possible. |
| Power |
315W |
| Size WxHxD |
365 x 105,3 x 252,5 mm (14,4"x4,1"x9,9") 9,66 L/dm³
|
| Operating Noise |
- |
|
| Weight |
4,00 kg / 8,82 lbs. |
| Keystone |
Vert.: +/-30°
|
| Illumination |
- |
| Frequenz |
H-sync: 19-92 kHz
V-sync: 48-92 Hz
|
| Foot-Lamberts |
99 fL
/ max. 493 cm screen width |
| Candela m² |
339 cd/m² |
| Features |
 Full HD 1080P compatible
Direkt Power Off
Freeze
Blank (Black screen button)
Eco Mode
Lan network compatible.
Crestron®-Software compatible.
Digital Zoom 4x
Automatic Dimming Mode
|
|
Optional only
Google TV /
Fire TV /
Apple TV /
Roku TV /
Xiaomi TV Ads |
In Comparison
The Sony VPL EX246 compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
38 |
Weight: |
|
81 |
| Contrast: |
|
1 |
dB: |
|
0 |
| Black level: |
|
96 |
Power cons.: |
|
97 |
| Picture Total Points: | 45 |
Projector Total Points: | 0 |
|
| Popularity Top 100 |
|
| Points: |
|
13 |
| Ranking: |
690 (From: 7662) |
|
|
|
|
|
| Status |
2013 Discontinued (EOL) // Last update of the data: 2023-08-04
Created: 2013-04-23 15:57:43
|
| Data |
 Product Sheet english
Product Sheet english
Product Sheet english HC
User Manual english (3.85 MB)
|
Sony Website
