Brief Introduction
Beta 2.5 |
A brief introduction to the PGWX-61B: The Barco stationary 3D DLP projector offers 6200 Ansi lumens, a contrast of 4000:1 and a WXGA 1280 x 800 resolution. The integrated lens shift provides freedom when positioning the projector. An image width of up to 800 cm is possible as the projector has 6200 Ansi lumens. The projector can create rooms with residual light with a smaller image width, we recommend a maximum of 533 cm. Playing 1080P and 3D is also no problem for the projector. The model was built by Barco in 2013 and is no longer current.
|
| Display Type |
1 x 0,65" DLP Chip
WXGA 16/10 Ti Digital Light Processing Chip
|
| Ansi-Lumen |
Projector |
6200 / 4500 im Eco Mode |
Screen |
2480 Lux (200 cm Screen width) |
| Contrast |
4000:1 full on/off |
4000:1 full on/off
|
| Black Level |
1,5500 min. Lumen |
0,62 min. Lumen |
| Lens shift |
Vert.: +/-50% Hori.: +/-14%
|
| Resolution |
WXGA 1280 x 800
1.024.000 Pixel |
| Video Modes |
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 3D, EDTV 480p, 576p |
| 3D Compatibility |
Frame-Packing (Full HD 3D) | Side-by-Side | Top-and-Bottom
Frame Sequential (3D Ready) |
| Application |
Stationary | Permanent installation in the training room and meeting room as well as the conference room.
Very large screen width and rooms with plenty of light and shaded daylight. |
| Light Source |
1 x 465W Ushio Lamp
Article Nr.: R9832774
|
|
| Light Life |
1500 h. 2000 h. in eco Mode |
| Operating Costs |
-
|
|
|
 |
|
Lux: |
2480 Lux |
|
Room light max.: |
496 Lux |
|
Candela pro m²: |
788 cd/m² |
|
Foot-Lamberts: |
230 fL |
|
 |
| 63 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Powered |
| Zoom |
Powered |
| Objective |
|
| Throw Ratio |
optional |
| Audio |
Nein |
| Connections |
HDMI 1.3 in
DVI-D in
D-sub 15pin in
5 x BNC RGBHV in
Cinch Video in
S-Video in
RS232C Din 9 pin in
RJ45 in |
| Ceiling Mounting |
Yes, is possible. |
| Power |
585 / 460W in Eco Mode |
| Size WxHxD |
475 x 253,6 x 565 mm (18,7"x10"x22,2") 67,9 L/dm³
|
| Operating Noise |
40 / 37 dB in Eco Mode |
Shift: 63 cm
|
Shift: 28 cm
|
|
Shift: 28 cm
|
| |
|
|
| Weight |
17,00 kg / 37,48 lbs. |
| Keystone |
- |
| Illumination |
85% |
| Frequenz |
- |
| Foot-Lamberts |
230 fL
/ max. 800 cm screen width |
| Candela m² |
788 cd/m² |
| Features |
 Real Full HD 3D
Full HD 1080P compatible
Lens shift Funktion
Eco Mode
Lan network compatible.
RGBYCW colour wheel
|
|
Optional only
Google TV /
Fire TV /
Apple TV /
Roku TV /
Xiaomi TV Ads |
In Comparison
The Barco PGWX-61B compared to others not current "Stationary" projectors. |
| Ansi-Lumen: |
|
61 |
Weight: |
|
94 |
| Contrast: |
|
1 |
dB: |
|
93 |
| Black level: |
|
95 |
Power cons.: |
|
93 |
| Picture Total Points: | 52 |
Projector Total Points: | 93 |
|
| Popularity Top 100 |
|
| Points: |
|
25 |
| Ranking: |
979 (From: 2514) |
|
|
|
|
|
|
Optional Lenses |
|
| Name | Ratio | Distance | Shift V | Shift H | Zoom |
| R9832756 | 1.52-2.92:1 | 304-584 m |
+/-50% |
+/-14% |
Powered |
| 1.26-1.58 : 1 | 1.26-1.58:1 | 252-316 m |
+/-50% |
+/-14% |
Powered |
| R9832754 | 1.22-1.53:1 | 244-306 m |
+/-50% |
+/-14% |
Powered |
| R9832755 | 0.95-1.22:1 | 190-244 m |
+/-50% |
+/-14% |
Powered |
|
| Status |
2013 Discontinued (EOL) // Last update of the data: 2025-03-03
Created: 2013-09-19 15:07:13
|
| Data |
 Product Sheet english
Product Sheet english HC
Quick Start Guide

|
Barco Website
