Brief Introduction
Beta 2.5 |
The home cinema EH TW6100W 3D LCD projector from Epson has 2300 Ansi lumens, a contrast of 40000:1 and an HDTV 1920 x 1080 resolution. The manufacturer Epson specifies a lamp life of 4000 hours, which converts to over 5.5 years at 2 hours per day. The projector is equipped with an integrated media player, so direct playback of files will not be a problem. As the projector has horizontal and vertical keystone correction, the projector can be set up with plenty of free space in the room. An image width of up to 487 cm is possible as the projector has 2300 Ansi lumens. However, if there is room light, the picture should be a maximum of 325 cm wide. Playing 1080P and 3D is also no problem for the projector. On the market since 2012, the model is no longer offered by the manufacturer Epson, but is still very popular in our projector database.
|
| Display Type |
3 x 0,61" LCD TFT Panel mit MLA
HDTV 16/9 Liquid Crystal Display with Micro Lense Array
|
| Ansi-Lumen |
Projector |
2300 |
Screen |
1022 Lux (200 cm Screen width) |
| Contrast |
40000:1 full on/off |
40000:1 full on/off
|
| Black Level |
0,0575 min. Lumen |
0,026 min. Lumen |
| Offset |
50% show
|
| Resolution |
HDTV 1920 x 1080
2.073.600 Pixel |
| Video Modes |
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 3D, EDTV 480p, 576p
Media player formats: JPEG |
| Disc Recognition |
DVD | HD Blu-ray | 3D Blu-ray | 4K UHD Blu-ray |
| 3D Compatibility |
Frame-Packing (Full HD 3D) | Side-by-Side | Top-and-Bottom
Frame Sequential (3D Ready) | 2D-zu-3D Video Converter |
| Application |
Homecinema | Medium screen width or rooms with little light, max. 100 lumens. |
| Light Source |
230W UHE Lamp
Article Nr.: ELPLP68 / V13H010L68
|
|
| Light Life |
4000 h. 5000 h. in Eco Mode |
| Operating Costs |
-
|
|
264 - 430 cm
|
 |
|
Lux: |
1022 Lux |
|
Room light max.: |
204 Lux |
|
Candela pro m²: |
325 cd/m² |
|
Foot-Lamberts: |
95 fL |
|
 |
| 56 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,63 |
| Objective |
F=1,51-1,99 f=18,2-29,2 mm |
| Throw Ratio |
1,32-2,15:1 show |
| Audio |
2 x 10W |
| Connections |
2 x HDMI 1.4 in
D-sub 15 pin in
YUV in
S-Video in
Cinch Video in
Cinch Stereo in
RS232C Din 9 pin in
RJ45 in
USB
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
358W |
| Size WxHxD |
365 x 137,3 x 420 mm (14,4"x5,4"x16,5") 21 L/dm³
|
| Operating Noise |
24 dB in Eco Mode |
Key: 208 cm |
Key: 152 cm |
| Key: 152 cm |
| |
|
|
| Weight |
6,20 kg / 13,67 lbs. |
| Keystone |
Vert.: +/-30°
Hori.: +/-30°
|
| Illumination |
- |
| Frequenz |
H-sync: 15,63 - 91 kHz
V-sync: 50 - 85 Hz
|
| Foot-Lamberts |
95 fL
/ max. 487 cm screen width |
| Candela m² |
325 cd/m² |
| Features |
 Real Full HD 3D
Full HD 1080P compatible
Direkt Power Off
Integrated Mediaplayer
Eco Mode
Kensington Slot
Gamma correction
Lan network compatible.
Overscan adjustable
With WirelessHD
|
|
Optional only
Google TV /
Fire TV /
Apple TV /
Roku TV /
Xiaomi TV Ads |
In Comparison
The Epson EH TW6100W compared to others not current "Homecinema" projectors. |
| Ansi-Lumen: |
|
21 |
Weight: |
|
100 |
| Contrast: |
|
1 |
dB: |
|
0 |
| Black level: |
|
99 |
Power cons.: |
|
91 |
| Picture Total Points: | 40 |
Projector Total Points: | 0 |
|
| Popularity Top 100 |
|
| Points: |
|
13 |
| Ranking: |
220 (From: 984) |
|
|
|
|
|
| Status |
2012 Discontinued (EOL) // Last update of the data: 2023-08-04
Created: 2013-09-03 12:44:21
|
| Data |
 Product Sheet english
Product Sheet english HC
User Manual english (4.4 MB)
|
Epson Website
