Brief Introduction
Beta 2.5 |
A brief introduction to the LV X320: The Canon DLP projector offers 3200 Ansi lumens, a contrast of 10000:1 and an XGA 1024 x 768 resolution. The manufacturer specifies a lamp life of 4000 hours, which is over 5.5 years if enjoyed for two hours every day. As the projector has horizontal and vertical keystone correction, the projector can be set up with plenty of free space in the room. Thanks to the brightness of 3200 Ansi lumens, a picture width of 493 cm is possible. In room light, the image should be max. 329 cm wide. The HDMI MHL (Mobile High-Definition Link) port allows 1080p / 60 Hz image mirroring (screen mirroring) to be transmitted from the smartphone while it is being charged at the same time via the connection. The model is also Full HD 1080P compatible. The model built in 2015 is no longer offered by Canon.
|
| Display Type |
1 x 0,55" DLP Chip
XGA 4/3 Ti Digital Light Processing Chip
|
| Ansi-Lumen |
Projector |
3200 / 2550 im Eco Mode |
Screen |
1067 Lux (200 cm Screen width) |
| Contrast |
10000:1 full on/off |
10000:1 full on/off
|
| Black Level |
0,3200 min. Lumen |
0,107 min. Lumen |
| Offset |
60% show
|
| Resolution |
XGA 1024 x 768
786.432 Pixel
UXGA 1600 x 1200 compressed |
| Video Modes |
Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with a little more ambient light, max. 200 lumens. |
| Light Source |
210W Lamp
Article Nr.: LV-LP40 / 0120C001
|
|
| Light Life |
4000 h. 6000 h. in Eco Mode |
| Operating Costs |
|
|
392 - 430 cm
|
 |
|
Lux: |
1067 Lux |
|
Room light max.: |
213 Lux |
|
Candela pro m²: |
339 cd/m² |
|
Foot-Lamberts: |
99 fL |
|
 |
| 90 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,1 |
| Objective |
F=2,56-2,8 f=21-24,10 mm |
| Throw Ratio |
1,96-2,15:1 show |
| Audio |
10W Mono |
| Connections |
HDMI 1.3 mit MHL in
2 x D-Sub 15 pin in
S-Video in
Cinch Video in
Mini Jack Audio in und out
USB Typ B
RS232C Din 9 pin in
RJ45 in
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
350 / 240W in Eco Mode |
| Size WxHxD |
282 x 115 x 232 mm (11,1"x4,5"x9,1") 7,52 L/dm³
|
| Operating Noise |
36 / 29 dB in Eco Mode |
Key: 316 cm |
Key: 226 cm |
| Key: 226 cm |
| |
|
|
| Weight |
2,50 kg / 5,51 lbs. |
| Keystone |
Vert.: +/-30°
Hori.: +/-30°
|
| Illumination |
80% |
| Frequenz |
- |
| Foot-Lamberts |
99 fL
/ max. 493 cm screen width |
| Candela m² |
339 cd/m² |
| Features |
 Full HD 1080P compatible
Eco Mode
Kensington Slot
PJLink™
Lan network compatible.
Crestron®-Software compatible.
Digital Zoom 2x
|
|
über HDMI MHL |
In Comparison
The Canon LV X320 compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
38 |
Weight: |
|
88 |
| Contrast: |
|
1 |
dB: |
|
33 |
| Black level: |
|
99 |
Power cons.: |
|
96 |
| Picture Total Points: | 46 |
Projector Total Points: | 72 |
|
| Popularity Top 100 |
|
| Points: |
|
6 |
| Ranking: |
4697 (From: 7662) |
|
|
|
|
|
| Status |
2015 Discontinued (EOL) // Last update of the data: 2023-09-20
