A projector from Eiki is the LC SX4LA, whose Laser-LCD model delivers 5800 ANSI lumens, a resolution of SXGA 1280 x 1024 and a contrast of 600:1. The manufacturer specifies a runtime of 1000 hours for this projector's lamp. Thanks to the combination of optical lens shift and digital keystone correction, the projected image's position can be adjusted very flexibly. To meet a wide variety of installation conditions, the projector offers the option of using different interchangeable lenses. Verifying the respective distances is easily possible via the Distance Calculator. Regarding projection size, the value of 5800 ANSI lumens allows for an image width of up to 645 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 430 cm. The projector was released in 2002 and is officially no longer distributed by Eiki.
Display Type
3 x 1,8" LCD TFT Panel mit MLA und PBS SXGA 5/4 Liquid Crystal Display with Micro Lense Array
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Wide screen width or rooms with plenty of light (over 200 lumens).
Calculated brightness quality The screen width may also be larger. Perfect
Lux:
1813 Lux
Contrast:
600:1
Candela pro m²:
576 cd/m²
Foot-Lamberts:
168 fL
80 cm
•
Focus
Powered
Zoom
Powered
Objective
Throw Ratio
optional
Audio
3W Stereo
Connections
Input Module 1:
1: DVI - DVI x 1 data, RCA x 2 audio, 8-pin DIN x 1 control Input Module 2: 2: RGB/DVD/HD BNC x 5 video, RCA x 2 audio, 8-pin Input Module 3: 3: Y/C BNC x 2 & S-Video x 1 video, RCA x 2 audio Audio Out (Stereo) RCA x 2 (L&R)
Ceiling Mounting
Yes, is possible.
Power
550W
Size WxHxD
664 x 523 x 827 mm (26,1"x20,6"x32,6") 287,19 L/dm³
Operating Noise
40dB
Shift: 80 cm
Shift: 80 cm
Weight
20,50 kg / 45,19 lbs.
Keystone
Vertical
Illumination
-
Frequenz
H-sync: 15-120 kHz V-sync: 50-120 Hz Range max.: 230 MHz
Lens shift Funktion motorisch max.
