Brief Introduction
Beta 2.5 |
The standard portable EMP S5 LCD has 2000 Ansi lumens, a contrast of 400:1 and an SVGA 800 x 600 resolution. 389 cm image width, the projector will be able to illuminate well. However, if room light is available, the image width should ideally not exceed 259 cm. This model is no longer offered by Epson.
|
| Display Type |
3 x 0,55" LCD TFT Panel
SVGA 4/3 Liquid Crystal Display
|
| Ansi-Lumen |
Projector |
2000 / 1600 im Eco Mode |
Screen |
667 Lux (200 cm Screen width) |
| Contrast |
400:1 full on/off |
400:1 full on/off
|
| Black Level |
5,0000 min. Lumen |
1,68 min. Lumen |
| Offset |
40,57% show
|
| Resolution |
SVGA 800 x 600
480.000 Pixel
UXGA 1600 x 1200 compressed |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, EDTV 480p, 576p |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with little light, max. 100 lumens. |
| Light Source |
170W UHE Lamp
Article Nr.: ELPLP41 V13H010L41
|
|
| Light Life |
3000 h. 4000 h. in Eco Mode |
| Operating Costs |
-
|
|
298 cm (no Zoom)
|
 |
|
Lux: |
667 Lux |
|
Room light max.: |
133 Lux |
|
Candela pro m²: |
212 cd/m² |
|
Foot-Lamberts: |
62 fL |
|
 |
| 61 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
No Zoom |
| Objective |
F=1,44 f=16,6mm |
| Throw Ratio |
1,49:1 |
| Audio |
1W Mono |
| Connections |
D-sub 15pin in und out
S-Video in
Cinch Video in
Cinch Stereo in
USB Typ B
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
231W / 5,8 standby |
| Size WxHxD |
327 x 92 x 245 mm (12,9"x3,6"x9,6") 7,37 L/dm³
|
| Operating Noise |
35 / 28 dB in Eco Mode |
|
| Weight |
2,60 kg / 5,73 lbs. |
| Keystone |
Vert.: +/-30°
|
| Illumination |
- |
| Frequenz |
H-sync: 15-92 kHz
V-sync: 50-85 Hz
Range max.: 162 MHz |
| Foot-Lamberts |
62 fL
/ max. 389 cm screen width |
| Candela m² |
212 cd/m² |
| Features |
 Freeze
Eco Mode
Kensington Slot
sRGB
Password protection
Digital Zoom
Quick-Start and Instant-Off: warm-up and cool-down time approx. 5 sec.
|
|
- |
In Comparison
The Epson EMP S5 compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
23 |
Weight: |
|
88 |
| Contrast: |
|
1 |
dB: |
|
36 |
| Black level: |
|
81 |
Power cons.: |
|
98 |
| Picture Total Points: | 35 |
Projector Total Points: | 74 |
|
| Popularity Top 100 |
|
| Points: |
|
13 |
| Ranking: |
672 (From: 7662) |
|
|
|
|
|
| Status |
2007 Discontinued (EOL) // Last update of the data: 2023-08-04
|
