EPSON EMP-83H
| EPSON EMP-83E
|
| Customer review |
|
 |
|
Brief Introduction
Beta 2.5 |
A brief introduction to the EMP 83/E/H: The Epson LCD projector offers 2200 Ansi lumens, a contrast of 400:1 and an XGA 1024 x 768 resolution. 2200 Ansi lumens ensure that an image width of 408 cm is also possible. However, if room light is available, the picture should be max. 272 cm wide. This model is no longer offered by Epson, but is still very popular in our projector database.
|
| Display Type |
3 x 0,63" LCD TFT Panel mit MLA
XGA 4/3 Liquid Crystal Display with Micro Lense Array
|
| Ansi-Lumen |
Projector |
2200 / 1760 im Eco Mode |
Screen |
733 Lux (200 cm Screen width) |
| Contrast |
400:1 full on/off |
400:1 full on/off
|
| Black Level |
5,5000 min. Lumen |
1,846 min. Lumen |
| Offset |
39,5% show
|
| Resolution |
XGA 1024 x 768
786.432 Pixel
UXGA 1600 x 1200 compressed |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, EDTV 480p, 576p |
| Application |
Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with little light, max. 100 lumens. |
| Light Source |
170W UHE Lamp
Article Nr.: V13H010L42
|
|
| Light Life |
3000 h. 4000 h. in Eco Mode |
| Operating Costs |
-
|
|
282 - 339 cm
|
 |
|
Lux: |
733 Lux |
|
Room light max.: |
147 Lux |
|
Candela pro m²: |
233 cd/m² |
|
Foot-Lamberts: |
68 fL |
|
 |
| 59 cm
|
|
Screen width: 200 cm Gain:1 |
|
|
| Focus |
Manual |
| Zoom |
Manual 1,2 |
| Objective |
F=1,60-1,74 f=18,4-22,12 mm |
| Throw Ratio |
1,412-1,697:1 show |
| Audio |
7W Mono / 7W Mono EMP-83H |
| Connections |
2 x D-sub 15pin in 1 x out
S-Video in
Cinch Video in
Cinch Stereo in
RJ45 in
RS232C
 |
| Ceiling Mounting |
Yes, is possible. |
| Power |
231W / 5,8W standby |
| Size WxHxD |
327 x 92 x 245 mm (12,9"x3,6"x9,6") 7,37 L/dm³
|
| Operating Noise |
35 / 28 dB in Eco Mode |
|
| Weight |
2,90 kg / 6,39 lbs. |
| Keystone |
Vert.: +/-30°
|
| Illumination |
- |
| Frequenz |
H-sync: 15-92 kHz
V-sync: 50-85 Hz
Range max.: 162 MHz |
| Foot-Lamberts |
68 fL
/ max. 408 cm screen width |
| Candela m² |
233 cd/m² |
| Features |
 Freeze
Blackboard Modus
Eco Mode
Kensington Slot
sRGB
Password protection
PJLink™
Lan network compatible.
Modell E ist mit Bedienerschutz.
|
|
- |
In Comparison
The Epson EMP 83/E/H compared to others not current "Standard-Portabel" projectors. |
| Ansi-Lumen: |
|
26 |
Weight: |
|
86 |
| Contrast: |
|
1 |
dB: |
|
36 |
| Black level: |
|
79 |
Power cons.: |
|
98 |
| Picture Total Points: | 35 |
Projector Total Points: | 73 |
|
| Popularity Top 100 |
|
| Points: |
|
30 |
| Ranking: |
31 (From: 7662) |
|
|
|
| Please note |
Model E is with operator protection.
|
|
|
| Status |
2007 Discontinued (EOL) // Last update of the data: 2023-08-04
|
| Data |
 Product Sheet english
Product Sheet english
Product Sheet english HC
Product Sheet französisch
Product Sheet USA PowerLite
Quick Start Guide
Quick Start Guide PowerLite
User Manual PowerLite english (2.48 MB)

|
|
|
Autor:
Epson emp-83h 10.08.12 |
|
5 Stars |
Sale |
|
I still have one of these at home if interested.
220 lamp hours down first.
|
|
|
Autor:
Felix 25.01.12 |
|
4.5 Stars |
Good projector |
|
I also use the projector privart, although it is now actually a business projector, although it is also ideally suited for private purposes. It has a good resolution and also works perfectly in other respects. It really makes a lot of noise. In addition, the menu is no longer up to date.
|
|
|
Autor:
Epson Freak 23.09.08 |
|
4.8 Stars |
Good projector |
|
We use the emp83 h in our company and also watched the European Championships with the projector. Everything was fine.
|
|
|
Autor:
Carsten 23.09.08 |
|
4.5 Stars |
Why this bad review?? |
|
Surely the black level is not the best, and the contrast of 400:1...(3LCD XGA normal)
But I am very satisfied with the device. The fan is pleasantly quiet, it plays HDTV material, the additional functions are well above the normal price level and the build quality is TOP. If you want an affordable projector (price/performance ratio), this is a good choice.
|
|
|
|
